BPV5iW Wide Inset Multi Fuel Stove
This stove is a larger version of the BPV5i. It offers all the same attributes but gives a larger viewing window and fuel capacity, making it ideal for the larger living space.
• Super high-quality cast ceramic firebox liners offer superior appearance and durability
with self-cleaning characteristics
• Optimal top flue connection on all our inset models facilitates installation where lintels
may obstruct other stoves
• Reduced clearances of 100mm from the legs of existing wooden surrounds as
standard and 275mm from a wood mantel when using the optional deflector shield
• Full multi-fuel capability as standard, so no kits or adaptors needed for burning
smokeless fuels
• 3.8-8kW operating range.
Specifications:
- Model Name: Purevision HD BPV5iW (Inset)
- Fuel: Solid Fuel or Wood
- Flue: Top
- Flue Diameter: 127mm (5")
- Finish: Black
- Appliance Gross Weight: 91kg
- Efficiency: 80.2%
- Nominal Heat Output: 5kW
- Approx Output Range: 3.1kW to 6kW
- Max Log Length: 300mm
- Warranty: 12 Years
Technical information:
-
Additional Features
- 12mm Hearth Friendly
- Constructional Hearth Required
- Direct Air Kit Available
-
Position
-
Finish
-
Colour
-
Flue Exit
-
Emission Standards
- EcoDesign Ready
- DEFRA Approved
-
Flue Diameter
-
Fuel Option
-
Style
DIMENSIONS:
Width: 412 mm
Height: 595 mm
Depth: 357 mm
FRAME SIZE:
Width: 493 mm
Height (3 Sided): 595 mm
Height (4 Sided): 612 mm
DISTANCE TO COMBUSTIBLE MATERIALS:
Sides (Surround Legs): 150 mm
Above (With/Without Deflector): 250 / 500 mm
